HCH Ultrafine Grinding Mill - best milling machine

HCH Ultra-fine Mill, High-tech Equipment, High Capacity and Energy Saving,Ultra-Fine-Grinding Mill

Max feeding size: 10mm
Capacity: 0.7-22t/h
Fineness: 0.04-0.005mm

With years’ accumulation of experience in R&D, the HCH Ultra-fine Mill is a new ultra-fine pulverizing equipment designed by Hongcheng. This mill is widely used to grind any non-metal minerals with Mohs hardness below 7 and moisture below 6%, such as talc, calcite, calciumcarbonate, dolomite, bentonite, kaolin, graphite, carbon black, etc. This kind of mill is especially suitable for ultra-fine grinding. HCH Ultra-fine Mill features in space-saving, completeness, wide usage, easy operation, smooth performance, high performance-cost ratio, high efficiency.an ultrafine grinding mill

---

With years' accumulation of experience in R&D, the HCH Ultra-fine Mill is a new ultra-fine pulverizing equipment designed by Hongcheng. This mill is widely used to grind any non-metal minerals with Mohs hardness below 7 and moisture below 6%, such as talc, calcite, calcium carbonate, dolomite, bentonite, kaolin, graphite, carbon black, etc. This kind of mill is especially suitable for ultra-fine grinding.

HCH Ultra-fine Mill features in space-saving, completeness, wide usage, easy operation, smooth performance, high performance-cost ratio, high efficiency.

---

1. High efficiency and high output, low cost and no pollution:

(1) Large reduction ratio, high usage of energy. Non-metal material under 15mm in size can be processed into micro-powder under 10µm in size (D97), 40% is 3µm fine powder, which has large specific surface area. The equipment has the advantages of high output and low cost, and can produce ultra-fine powder.

(2) HCH1395 Ultra-fine Mill is the largest ring roller mill in China. With an output of 11t/h, the equipment break the problem of the large-scale producing of ring roller mill.

(3) Lower energy consumption, no pollution. The equipment operates under negative pressure, installed with larger dust remover, offing a low dust environment; applied with semi-automatic control and special technology to improve capacity, the equipment is one of the lowest energy consumption ultra-fine mill.

2. Reliable operation, easy maintenance:

(1) Stable operation, the main mill has special and high performance classifying device. The production quality is high and has no large particle pollution. It is an ideal equipment in non-metal fine powder dry processing.

(2) Grinding wheel and ring are cast by special wear-resistant steel, which has long service time. It also reduce the time and labor cost of maintenance.

(3) Main mill pedestal applied single-casting structure, ensuring structural strength and lower the vibration.

3. Complete set, wide usage:

(1) The equipment organized a complete production system from material crushing, transporting, grinding to production collecting, storing and packing.

(2) The main mill is installed with classifying system, production fineness can be adjusted. The equipment has wide application in producing fine powder of D97=3-8µm or normal powder of D97=10-40µm.

4. High cost effective, low investment cost:

(1) The mill is in stereo-chemical structure, which lower the floor space and construction cost;

(2) The mill is applied in ultra-fine powder processing, the construction and operation cost is low but has high efficiency.

------

Model	Max Feeding Size (mm)	Fineness(mm)	Capacity (t/h)	Weight (t)	Total Power (kw)
HCH780	≤10	0.04-0.005	0.7-3.8	17.5	144
HCH980	≤10	0.04-0.005	1.3-6.8	20	237
HCH1395	≤10	0.04-0.005	2.6-11	44	395
HCH2395	≤10	0.04-0.005	5-22	70	680

Fineness(mesh) Capacity(kg/h)	400	600	800	1250	1500	2500
HCH780	3200-3800	2200-2800	1800-2200	1200-1800	1000-1200	700-900
HCH980	6000-6800	4500-5000	3900-4500	2500-3000	2100-2500	1300-1600
HCH1395	10000-11000	8000-8500	6200-7800	4200-4800	3600-4200	2600-3100
HCH2395	20000-22000	16000-17000	12400-15600	8400-9600	7200-8400	5200-6200

Note:The capacity is for calcite powder(Feeding Size≤10), and specification is just a reference. The actual production depends on these materials being processed.
